Diodos de recuperación estándar(Stud versión)

Model

IF_(AV)

V_FM/I_FM

IF_(RMS)

V_RRM

I_RRM

R_jc

T_j

M²

Wt

Outline

Temp.

T_HS55℃

25℃

/

A

V

A

A

V

mA

℃/W

℃

N/m

Kg

/

6F(R)

6

1.1

18

9.0

200~1200

≤6

≤2.0

-40

~

+150

≤1.0

0.008

DO-4

12F(R)

12

1.1

36

19.0

200~1200

≤6

≤1.2

≤1.0

0.008

DO-4

16F(R)

16

1.25

48

25.0

200~1200

≤12

≤1.2

≤1.0

0.008

DO-4

25F(R)

25

1.1

75

40.0

200~1200

≤12

≤1.2

≤1.0

0.008

DO-4

30HF(R)

30

1.3

90

48.0

200~1200

≤10

≤0.8

≤2.0

0.020

DO-5

40HF(R)

40

1.3

120

64.0

200~1200

≤10

≤0.8

≤2.0

0.020

DO-5

50HF(R)

50

1.4

150

80.0

200~1200

≤10

≤0.8

≤2.0

0.020

DO-5

60HF(R)

60

1.4

180

96.0

200~1200

≤12

≤0.6

≤2.0

0.020

DO-5

70HF(R)

70

1.45

210

112.0

200~1200

≤12

≤0.5

≤2.0

0.020

DO-5

85HF(R)

85

1.45

255

136.0

200~1600

≤12

≤0.4

≤2.0

0.020

DO-5

100U (R)

100

1.8

300

160.0

200~1600

≤15

≤0.3

≤12

0.120

DO-8

150U(R)

150

1.5

450

240.0

200~1600

≤15

≤0.3

≤12

0.120

DO-8

100U(R)L

100

1.8

300

160.0

200~1600

≤15

≤0.3

≤12

0.140

DO-30

150U(R)L

150

1.5

450

240.0

200~1600

≤15

≤0.3

≤12

0.140

DO-30

200U(R)

200

1.3

600

320.0

200~1800

≤20

≤0.2

≤12

0.250

DO-9

250U(R)

250

1.35

750

400.0

200~1800

≤20

≤0.15

≤25

0.250

DO-9

300U(R)

300

1.35

900

480.0

200~1800

≤20

≤0.15

≤25

0.250

DO-9

SD400N(R)

400

1.6

1200

640.0

200~2400

≤40

≤0.07

≤25

0.580

B-8

SD500N(R)

500

1.6

1500

800.0

200~2400

≤40

≤0.065

≤25

0.580

B-8

SD600N(R)

600

1.5

1800

960.0

200~2400

≤40

≤0.065

≤30

0.580

B-8
