SSR-D Series Solid State Relay (DC-AC)
Features
■Current: 0.5-400A
■Voltage: 24-440V
■All models feature the same compact dimensions to prolide a
uniform mounting pitch
■Built-in MOV effectively absorbs extermal surges
■Operation indicaor (red LED) enables monitoring operation
■Protective cover for greater saftey
■Conform to IEC international electrical committee standard
■DC and AC, AC and AC, DC and DC, AC and DC input versions available
Typical Applications
■Universal switch and thermal control
■Industrial automatic control
■Numerial-controlled machinery,
■remote-control system
|
Rated load current |
Operating voltage |
Min. On voltage |
Min. OFF voltage |
Trigger current |
Load voltage |
Black voltage |
Voltage drop |
Peak current |
Leakage current |
Turn-on or off time |
Insulation voltage |
Tj |
Outline |
|
A |
V |
V |
V |
12V |
V |
V |
V |
A |
mA |
ms |
V |
℃ |
|
|
5 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
130 |
3.0 |
10 |
2500 |
-30
+80 |
SSR1/2 |
|
10 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
135 |
3.0 |
10 |
2500 |
||
|
20 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
270 |
3.0 |
10 |
2500 |
||
|
25 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
275 |
3.0 |
10 |
2500 |
||
|
30 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
300 |
3.0 |
10 |
2500 |
||
|
40 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
410 |
3.0 |
10 |
2500 |
||
|
50 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
500 |
3.0 |
10 |
2500 |
||
|
60 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
635 |
3.0 |
10 |
2500 |
||
|
70 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
700 |
3.0 |
10 |
2500 |
||
|
75 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
850 |
3.0 |
10 |
2500 |
||
|
80 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
900 |
3.0 |
10 |
2500 |
||
|
90 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
990 |
3.0 |
10 |
2500 |
||
|
100 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
1100 |
3.0 |
10 |
2500 |
||
|
120 |
3-32 |
>2.4 |
<1.0 |
7.5mA |
240/480 |
600 |
2.0 |
1250 |
3.0 |
10 |
2500 |
