Russian Type Fast Recovery Diodes (Stud Version)
Features：
Hermetic metal case with ceramic/glass insulator
Stud cathode and stud anode version
Wide current range
High surge current capability
High dynamic characteristics
Low on-state Voltage drop and switching loss
Application：
Big power transformer
Battery charges
Converters
Power supplies
Welder
Lighting Circuits
Motor controls
Machine tool controls
|
Type |
VRRM |
IRRM |
IF(AV) |
IF(RSM) |
IF(SM) |
IF(SM) |
Trr |
Tj |
Rjc |
M2 |
Wt |
Outline |
|
|
|
Tc55℃ |
|
10ms |
10ms |
|
|
|
|
|
||
|
|
V |
mA |
A |
A |
kA |
kA |
μs |
℃ |
℃/W |
N/m |
kg |
|
|
DF212-10 |
400-1400 |
10 |
10 |
16 |
0.18 |
2.30/31 |
0.5 |
-40 ~ +150 |
2.50 |
0.9 |
0.006 |
RSD1 |
|
DF212-16 |
400-1400 |
10 |
16 |
25 |
0.25 |
2.30/50 |
0.5 |
1.60 |
0.9 |
0.006 |
RSD1 |
|
|
DF212-20 |
400-1400 |
10 |
20 |
31 |
0.31 |
2.30/62 |
0.5 |
1.20 |
0.9 |
0.006 |
RSD1 |
|
|
DF222-25 |
400-1400 |
15 |
25 |
39 |
0.40 |
2.30/78 |
0.5 |
1.00 |
1.4 |
0.015 |
RSD2 |
|
|
DF222-32 |
400-1400 |
15 |
32 |
50 |
0.50 |
2.30/98 |
0.5 |
0.80 |
1.4 |
0.015 |
RSD2 |
|
|
DF232-40 |
400-1400 |
20 |
40 |
62 |
0.60 |
2.30/125 |
0.7 |
0.60 |
5.0 |
0.027 |
RSD3 |
|
|
DF232-50 |
400-1400 |
20 |
50 |
78 |
0.75 |
2.30/157 |
0.7 |
0.50 |
5.0 |
0.027 |
RSD3 |
|
|
DF232-63 |
400-1400 |
20 |
63 |
98 |
0.95 |
2.30/198 |
0.7 |
0.40 |
5.0 |
0.027 |
RSD3 |
|
|
DF141-63 |
400-1400 |
50 |
63 |
100 |
2.0 |
2.23/198 |
1.0, 2.0 |
0.45 |
6 |
0.090 |
RSD4 |
|
|
DF141-60 |
400-1400 |
30 |
80 |
125 |
2.5 |
1.58/250 |
4.8 |
0.45 |
6 |
0.090 |
RSD4 |
|
|
DF151-125 |
400-1400 |
30 |
125 |
200 |
4.0 |
2.04/390 |
2.0 |
0.25 |
10 |
0.165 |
RSD5 |
|
|
DF161-160 |
400-1400 |
20 |
160 |
250 |
3.5 |
2.45/500 |
3.2, 4.0 |
0.25 |
20 |
0.250 |
RSD6 |
|
|
DF161-200 |
400-1400 |
20 |
200 |
300 |
4.3 |
1.85/528 |
3.2, 4.0 |
0.25 |
20 |
0.250 |
RSD6 |
|
|
DF161-250 |
400-1400 |
30 |
250 |
390 |
4.5 |
2.71/785 |
3.2, 4.0 |
0.15 |
20 |
0.250 |
RSD6 |
|
|
DF171-320 |
400-1400 |
30 |
320 |
500 |
5.3 |
2.13/1000 |
5.0, 6.5 |
0.15 |
25 |
0.465 |
RSD7 |
