单相半控整流桥

型号
Type

VRRM VDRM

ID@TS

TS

ITSM IFSM
@Tjmax

VT(TO)
@Tjmax

rT(TO)
@Tjmax

Rth(j-s)
per chip

Tj

Case

外形
Outline

V

A

℃

A

V

mΩ

K/W

℃

WZSK50B06UF

600

46

80

400

0.8

11

0.45

-40~+150

2

M-49

WZSK50B

800-1600

51

80

270

0.8

13

1.7

-40~+150

2

M-49

WZSK55B06F

600

54

80

440

0.9

16

1.2

-40~+150

2

M-49

WZSK55B12F

1200

57

80

550

1.2

22

0.9

-40~+150

2

M-49

型号
Type

VRRM

VVRMS

IDAVM

@TH

@TC

IFSM
10ms Tvj45℃

VTO

rT
(mohms)

Tvjm

RthJC
perchip

RthJH
perchip

Ckt Diag

Package
style

Status

V

V

A

℃

℃

A

V

℃

K/W

K/W

WZVHF15

1400

440

15

85

-

190

1.00

40

125

2.40

3.00

VHF

FO-F-A

Active Part

WZVHF36

1400

440

36

85

-

320

0.85

13

125

1.15

1.55

VHF

FO-F-A

Active Part

WZVHF28

1400

440

28

85

-

300

0.90

15

125

1.40

2.00

VHF

FO-F-A

Active Part

WZVHF25

800

250

32

-

85

200

0.85

27

125

1.30

1.80

VHF

ECO-PAC1

Active Part
